Tapered Master Plugs

Used to quickly evaluate the wear state of spline ring gauges.

During the manufacturing process, ensures a close correlation ring to ring, for a given spline.  Enables quick wear inspection of ring gages and can be used as an alternate, for ring gages, to measuring between pins.



Standards

  • AGMA & ANSI, ISO, BS, DIN, Others

Material Options

  • O1 Tool Steel (58-60 HRc)

  • A2 Tool Steel (57-62 HRc)

The capacity stated is not fixed and may be reduced or increased dependant upon the gauge required.

Please place an inquiry and we will confirm the capacity against the gear/spline data.
